Heat Seal Test:
- Sealing Temperature: Room temperature~250 °C
- Sealing Pressure: 0.05 MPa~0.7 MPa
- Dwell Time: ≤99.9s
- Resolution: ±0.1°C
- Accuracy: ±2°C
- Temperature Gradient: ≤20°C
- Sealing Area: 55mm×10mm
- Number of Sealing Jaws: 3+1Note1
Hot Tack Test :
- Sealing Temperature: Room Temperature~250°C
- Resolution: ±0.1°C
- Accuracy: ±1°C
- Dwell Time (Heat Seal): ≤99.9s
- Dwell Time (Hot Tack): ≤20s
- Sealing Pressure: 0.05~0.7MPa
- Number of Sealing Jaws: 1＋1Note2
- Capacity Range: 0~50N (Optional)
- Test Accuracy: 1% FS
- Resolution: 0.1N
- Specimen Width: 15 mm or 25 mm or 25.4 mm
Heat Seal Strength:
- Capacity Range: 0~50N (Optional)
- Test Accuracy: 1% FS
- Resolution: 0.1N
- Specimen Width: 15 mm or 25 mm or 25.4 mm
- Speed: 200mm/min, 250mm/min, 300mm/min
(Customization is available)
- Stroke: 78.5 mm
O
Gas Supply: Air (Outside of supply scope)
Gas Supply Pressure: 0.05~0.7MPa
Port Size: Φ6 mm PU Tubing
Dimension: 500 mm (L) × 580 mm (W) × 575 mm (H)
Power Supply: 220VAC 50Hz / 120VAC 60HzNote3
Net Weight: 50 kg
Configurations
- Standard: Instrument (Including wireless data interface）, Embedded Software, Standard LCD Monitor, Keyboard, Mouse, Calibration Frame, Pedal Switch, Sample Cutter and Valve tubing Set, Printer
- Optional: Strip Sample Cutter, Unheated Sealing Jaw, Air Compressor and Desiccant
