Capacity (Optional): 50N, 100N, 250N, 500N, 1kN, 2.5kN, 5kN
Unit (switchable): N,kN,kgf,Lbf,MPa,Lbf/In²,kgf/mm²
Load Resolution: 1/500,000(0.5 Level), 1/250,000(1 Level)
Accuracy Grade of Machine: 0.5 Level/1 Level
Load Magnifying Rate: Section-less
Max Stroke (Exclude the Grips): 650 mm Standard, 850 mm Heighten Option
Effective Width: No Limit
Test speed: 0.001 ~ 500mm/min or others
Speed accuracy: ± 0.25% 0.5 Level/ ± 0.5% 1 Level
Displacement Resolution: 0.00004mm
Software: Closed-loop control software
Motor: AC Servo motor
Transmission Rod: High accuracy of ball screw
Main Unit Dimension (WxDxH): Standard: 585x505x1290mm, Heighten: 585x505x1490mm
Power: AC220/50HZ 10A or specified by user
