Temperature
Temperature Range: 25℃~80℃
Customizable to: −70℃ (customer request)
Temperature Fluctuation: ±0.5℃
Heating Rate: 25℃~80℃ (3~5℃/min)
Cooling Rate: 80℃~25℃ (1~2℃/min)
Temperature Uniformity: ±2℃
Humidity
Humidity Range (without illumination): 30%RH ~ 90%RH (temperature range: 20℃~70℃)
Humidity Range (with illumination): 30%RH ~ 80%RH (temperature range: 20℃~80℃)
Humidity Fluctuation: ±2% RH
Humidity Uniformity: ≤±3.0% (>75%RH) ≤±5.0% (≤75%RH)
Lighting Specification
Irradiation Intensity (300~850 nm): 550±10% W/m²
Irradiation Intensity (300~850 nm): 1200±20% W/m²
Xenon Lamp Power: 4.5 kW, 6 kW (water-cooled full-solar spectrum long-arc xenon lamp)
Sample Rotation Speed: 1 r/min
Distance Between Arc Center and Test Sample: 476~482 mm
Material
Internal Material: SUS304 Stainless Steel
External Material: Cold-rolled Plate, Powder Coating
Heat Insulation: Polyurethane Foam (100 mm) + Glass Wool (10 mm)
Fan: Centrifugal Fan (Impeller Fan)
Refrigeration Compressor: Hermetic Compressor (Tecumseh)
Cooling Mode: Air Cooling or Water Cooling
Refrigerant: R404A
Evaporator: Finned-tube Exchanger
Heater: Nickel Chrome Strip Heater
Humidifier: Steam Humidifier
Size & Operation
Interior Size (mm): 800(W)*800(H)*800(D)
Volume (L): 500 L
Working Temperature: +5 ~ 35℃
Power Supply: AC 380V 50Hz
