Rated Current: 1/5A
Rated Voltage: 120V (Used between 60 and 300 V.)
Operating Principle: Rectifier type
Class: JIS C 1102 : 1997 Class 3.0
Operating Position: Horizontal
Rated Frequency: 45 ~ 65 Hz
Scale Length: Approximately 135 mm (Deflection Angle: 85°)
Scale: Lead 0-0.3 to 1.0 to 0.3-0 lag (with phase angle scale)
Effective Measurement Range: Lead 0.5 to 1.0 to 0.5 lag
Approx. Consumed Power Voltage Circuit (120 V): 0.14 VA
Approx. Current Circuit (5 A): 2.4 VA
Operating Temperature Range: 0 ~ 40°C
Operating Humidity Range: 30 ~ 75% RH
Storage Temperature Range: -10 ~ 50°C
Storage Humidity Range: 25 ~ 80% RH
Dimension: 260 x 180 x 115 mm
Weight: 2.9 kg
