Hangings: 1 or 3 Hangings (2 kinds)
Die: φ2.095 ± 0.005 mm, L8.000 ± 0.025 mm
Piston: Head Diameter φ9.474 ± 0.007 mm, Head Length L6.35 ± 0.10 mm
Cylinder: Inner φ9.550 ± 0.007 mm, L160 mm
Temperature Range: Max. 300 °C (Option: Max. 400 °C)
Weight Load: Choose the Largest Load from 0.325, 1.20, 2.16, 3.80, 5.00, 10.00, 21.60 kgf
Test Method: Method A: Manual (Option: Automatic) Method B: Automatic
Accessories: Cleaning Rod (Die, Cylinder), Solvent Cleaning Device, Specimen Cup, Cup Holder, Infundibulum, Die Gauge, Spirit Level, Dust Box, Gauze, Air Gun
Option: Hastelloy Spec, Specimen Purging Device, Specimen Drying Device, Air Compressor, Temperature Calibration Device, Exhaust Fan (Standard for No.120-LABOT), Smoke-Detection Sensor: (Standard for No.120-LABOT)
Power Source: AC 100 V, 1-Phase, 15 A, 50/60 HzAC 200 V, 1-Phase, 20 A, 50/60 Hz (ISO-1133-2 Compatable Type)
Air Source: 0.5 MPa or More
Dimensions/ Weight (Approx.): 1 Hanging: W675× D645 × H1,370 mm/200 kg; 3 Hangings: W675 × D725 × H1,370 mm/ 220 kg
