Circulation Type: External closed circulation
Circulating Water: Tap water, nyrbine (liquid temperature below 10 °C)
Operation Temperature Range: 5 °C to 35 °C
Temperature Control Range: −20 °C to 30 °C
Temperature Adjustment Accuracy: JTM K05 ±1 °C
Temperature Fluctuation: JIS 3.0 °C
Cooling Capacity: Approx. 1320 W at 10 °C liquid temp; Approx. 700 W at −10 °C liquid temp
Max. Flow Rate (60 Hz): Approx. 14 L/min
Max. Lift (60 Hz): Approx. 14.3 m
Temperature Control: Refrigerator ON/OFF control
Temperature Sensor: Pt100Ω
Controller: White LED digital display, key input, minimum digit 1 °C
Refrigerator System / Rated Capacity / Refrigerant: Air-cooling / 650 W / R407C
Connection: One-touch connector (Flexible rotary L type)
External Circulation Nozzle: Outer diameter Ø10 mm rigid hose connection (inner Ø9 mm flexible hose with attached nozzle)
Water Circulating Pump (60 Hz): Magnet pump 65 W
Safety Features: Electric leakage breaker, temperature sensor abnormality, upper/lower temperature alarm, upper/lower temperature abnormality, refrigerator overload relay, fan motor protection, pump thermal protector, refrigerator protection delay timer, refrigerator high-pressure switch
Other Features: Drainage hose, circulation port condensation drainage hose, intake port dustproof filter, cooling operation switch, circulation pump switch, calibration offset, power failure recovery function (selected)
Inner Tank Material: Stainless steel
Inner Tank Capacity (Liquid Volume): Approx. 15.5 L (liquid volume 14 L)
External Dimensions: W340 × D370 × H838 mm
Weight: Approx. 43 kg
Power Source (60 Hz) / Rated Current: AC220 V 6 A (15 A)
Accessories: Hose nozzle × 2 pcs, condensation drain hose (Ø12 mm × 1 m) × 1 pc, hose clamp × 2 pcs
