Ultimate pressure: Depends on stream pressure at operating temperature
Ultimate vacuum: 1.2kPa（9.2Torr）at 10℃
Ultimate vacuum: 2.3kPa（17.5Torr）at 20℃
Ultimate vacuum: 4.2kPa（31.8Torr）at 30℃
Discharge rate: 50Hz 11〜13L/min×2
Discharge rate: 60Hz 12〜14L/min×2
Aspirator: O.D. 12mm (metal) x 2
Water tank: Polypropyrene resin made 10L
Circulation pump: 80W self-suction type Polypropyrene resin made
Vacuum controller (with pressure gauge): can be attached（Option）
Drainage method: Natural drainage by overflow
Suction port size: O.D. 12mm
External dimensions（W×D×H mm）: 360×250×360mm
Power Source: AC100V 2/2.3(50/60Hz)A
Weight: 9kg
