Air flow direction: Vertical direction (down flow) Forced circulation exhaust type (weak negative pressure)
Cleanliness: Class 100 (JIS Class 5)
Blow-off air speed (m/sec): Approx. 0.35 at early stage, Approx. 0.17 final
Illuminance (lx): 1000 (in the center of working face)
Load bearing of working face: 50kg (static load)
Air volume Work space: Approx.13 m3/min
Air volume Exhaust: Approx.1.5 m3/min
Flourescent lamp: 32W x 2pcs.
Blower (single phase): 150W x 1
Working surface level adjustment: Use adjusting foot (-18~+40mm)
Display of pressure difference: Differential pressure gauge
Gas burner: 1 pc/fire ignition type (can be used only when operating the machine)
Overcurrent protector: Earth leakage breaker 1pc
Optional item: Wind velocity controller: displays wind velocity and with wind adjust device attachment
Internal dimensions（H mm）: 720mm
External dimensions（W×D×H mm）: 980×770×1820mm
Power Source: AC115/220V Single-phase with step-down transformer
Weight: 190kg
