Width: 10.00 mm
Height: 4.54 mm
Length: 22.5 mm
Fall Time: 31 ns
Rise Time: 34 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: N-Channel
Qg - Gate Charge: 91 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 22 ns
Typical Turn-Off Delay Time: 89 ns
Id - Continuous Drain Current: 28 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 21 S
Rds On - Drain-Source Resistance: 115 mOhms
Vds - Drain-Source Breakdown Voltage: 600 V
Vgs th - Gate-Source Threshold Voltage: 5 V
