Width: 6.5 mm
Height: 1.6 mm
Length: 7.0 mm
Fall Time: 6 ns
Rise Time: 5 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 12 nC
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2.78 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 7 ns
Typical Turn-Off Delay Time: 16 ns
Id - Continuous Drain Current: 3 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 11 S
Rds On - Drain-Source Resistance: 135 mOhms
Vds - Drain-Source Breakdown Voltage: 100 V
Vgs th - Gate-Source Threshold Voltage: 3 V
