Width: 101.6 mm (4 in)
Height: 26.4 mm (1.039 in)
Length: 50.8 mm (2 in)
Industry: Medical, Industrial
Approvals: ANSI/AAMI ES60601-1, CSA, cUL62368-1, EN60601-1, EN62368-1, IEC60601-1, IEC60950-1, IEC62368-1
Compliance: ANSI/AAMI ES60601-1, CSA, cUL62368-1, EN60601-1, EN62368-1, IEC60601-1, IEC60950-1, IEC62368-1
Efficiency: 85 %
Unit Weight: 112 g
Output Power: 60 W
Input Voltage: 80 VAC to 264 VAC
Mounting Style: Panel
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 3.33 A
Output Voltage-Channel 1: 18 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 25 C
