Width: 50.8 mm (2 in)
Height: 30.4 mm (1.197 in)
Length: 101.6 mm (4 in)
Industry: Medical, Industrial
Approvals: ANSI/AAMI, CSA, cUL60950-1, EN60950-1, IEC60601-1, IEC60950-1
Compliance: ANSI/AAMI, CSA, cUL60950-1, EN60950-1, IEC60601-1, IEC60950-1
Efficiency: 88 %
Unit Weight: 155 g
Output Power: 60 W
Input Voltage: 85 VAC to 264 VAC
Mounting Style: Panel
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 2 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 7 A
Output Current-Channel 2: 2 A
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: 15 VDC
Operating Temperature Range: - 20 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
