Width: 63.5 mm (2.5 in)
Height: 30.5 mm (1.201 in)
Length: 114.3 mm (4.5 in)
Industry: Medical, Industrial
Approvals: ANSI/AAMI, CSA/cUL, EN60601-1, EN60950-1, UL60950-1
Compliance: ANSI/AAMI, CSA/cUL, EN60601-1, EN60950-1, UL60950-1
Efficiency: 85 %
Output Power: 80 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 2 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 12 A
Output Current-Channel 2: 3 A
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: 12 VDC
Operating Temperature Range: 0 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
