Capacity: 20 Kg
Non-linearity: ≤0.5%F.S.
Repeatability: ≤0.2%F.S.
Zero balance: ±2%F.S.
Operating temp range: -20~80°C
Compensated temp range: -10~40°C
Insulation: ≥2000MΩ/50VDC
Recommended excitation voltage: 5-10 VDC
Safe load limit: 150%F.S.
Temp effect on output: ≤0.1%F.S./10°C
Temp effect on zero: ≤0.1%F.S./10°C
Long-term crosstalk error: ≤1%F.S.
Protection class: IP65
Cable size: φ4.5*4m
