Max. swing over bed: 250mm
Max. swing over carriage: 110mm
Distance between centers: 450mm
Chuck size: 125mm
Spindle speed: 100-3000r/min
Spindle bore: 20mm
Spindle taper: MT3
Spindle power: 1000W
X axis travel: 90mm
Z axis travel: 320mm
Max. rapid speed: 2000mm/min
Max. feed speed: 500mm/min
Feed motor: 4Nm
Position of toolpost: 4
Tailstock taper: MT2
Tailstock dia.: 30mm
Tailstock travel: 50mm
Positioning accuracy: 0.015mm
Voltage: 230/110V
N.W/G.W: 360kg/410kg
Machine size (LxWxH): 1460×760×1450mm
Packing size (LxWxH): 1630×1070×1685mm
