Max. swing over bed: φ350mm
Distance between centers: 260mm
Max.swing over cross slide: φ185mm
Max. spindle speed: 4000rpm
Spindle bore: φ52mm
Spindle nose: A2-5
Taper of spindle bore: Metric 1:20
Chuck dia.: φ160mm
X-axis travel: 350mm
Z-axis travel: 300mm
Rapid traverse X/Z: 12/15 m/min
Tool section: 20x20mm
Spindle motor power: 4KW Servo
Spindle pump power: 120w
CNC controller: GSK 980TDI
Type of guideway: Taiwan linear guideway
Overall size (LxWxH): 2600x1300x1700mm
Packing size (LxWxH): 2760x1700x2050mm
N.W/G.W: 1350/1550kg
