Rated Voltage: 380V /3 phase AC Current
Rated Frequency: 50HZ
Total Input Power: 4.75kw
Min Setting Value: 0.001mm
Cutting Speed: 1–4000mm/min
X Axis Fast Feed Rate: 18000mm/min
Y Axis Fast Feed Rate: 18000mm/min
Z Axis Fast Feed Rate: 18000mm/min
Max. Bar Dia.: Φ20mm
Spindle Hole Dia.: Φ21mm
Height of spindle center from ground: 980mm
Spindle speed: 0-4000r/min
Spindle power: 2kw
Drilling Spindle Size: ER11/20mm
Cuting MotorPower: 0.09kw
Capacity of CoolingContairer: 150L
Motor Power: 25w
Capacity: 1.5L
Input Pressure of Compressed Air: 0.4–0.6Mpa
X Axis Stroke: 80mm（dia.）
Y Axis Stroke: 150mm
Z Axis Stroke: 250mm
X Axis Servo Motor Power: 0.75kw
Y Axis Servo Motor Power: 0.75kw
Z Axis Servo Motor Power: 0.75kw
L*W*H(mm): 1495*1010*1860mm, 1220kg
