Frequency range: 136.000-173.500 MHz
Channel spacing: 375 kHz
Modes:FM (DIFAR)
Sensitivity: 0.9 µV
IF bandwidth: 230 kHz @ -6 dB
Skirt selectivity: 470 kHz @ -25 dB; 730 kHz @ -60 dB
Frequency response:
5 Hz to 25 kHz @ ± 1 dB
5 Hz to 40 kHz @ ± 2 dB
Output level: 1.0 ± 0.2 V rms @ 75 kHz deviation and 1 kHz modulation frequency
RSSI range: 80 dB typ.
Image rejection: 70 dB or better
Tuning accuracy: ±1 ppm
Frequency stability: ±0.5 ppm
Input impedance: 50 ohm
Output impedance: 600 ohm
Connectors: SMA for RF input and demodulator output; 3.5 mm audio jack for monitor output
Interface: PCI 2.2 compliant
Total power consumption: 6 W
Dimensions:
Length: 195 mm (7.68")
(excluding mounting bracket)
Height: 99 mm (3.90")
(excluding edge connector)
Thickness: 19 mm (0.75")
(incl. components on either side)
Weight: 330 g (11.6 oz)
Ambient temperature:Storage: -20º to +75º C; Operation: 0º to +45º C
