Frequency range: 136.000-173.500 MHz
Channel spacing: 375 kHz
ModesFM (DIFAR)
Sensitivity: 0.9 µV
IF bandwidth: 230 kHz @ -6 dB
Skirt selectivity: 470 kHz @ -25 dB; 730 kHz @ -60 dB
Frequency response: 5 Hz to 25 kHz @ ± 1 dB; 5 Hz to 40 kHz @ ± 2 dB
Output level: 1.0 ± 0.2 V rms @ 75 kHz deviation and 1 kHz modulation frequency
RSSI range: 80 dB typ.
Image rejection: 70 dB or better
Tuning accuracy: ±1 ppm
Frequency stability: ±0.5 ppm
Input impedance: 50 ohm
Output impedance: 600 ohm
Connectors: 2 x SMA: RF input, demodulator output
Interface: USB (1.0 and 2.0 compatible)
Power requirements: 12 V DC @ 500 mA
Dimensions:
Length: 166 mm (6.5")
Width: 97 mm (3.8")
Height: 41 mm (1.6")
Weight:430 g (15.1 oz)
Ambient temperature:Storage: -20º to +75º C; Operation: 0º to +45º C
