International Standard: ASTM D 1646; ISO 289; KS M ISO 289-1, -2, -4
Motor: Induction Motor
Rotor: Disk-shaped rotor; Large and small
Rotor Speed: 2 rpm
Protection for operator: Before test chamber closing
Temp. shield screen moving: Before test chamber closing
Test chamber moving: By Pneumatic
Motor Platen operation: available by hardware & software
Temperature control: available by hardware & software
Temperature range: microprocessor controlled RT ~ 220°C
Temp. Sensor Type: PT 100 Ω
Torque range: 0~ 200 MU
Test modes: viscosity; scorch; stress relaxation; Stop T5 and T3 mode
Calibration: Weight and software
Data: Initial viscosity, ML[S]1+4[N]; Scorch viscosity and cure times; T5(3), T35(18) and T30(15), Tmin; [Multi] Stress relaxation; Data files convert to excel files; Trend graphs; Tolerance limits box by time and torque; Average, S-Dev, ERP system upload
Pneumatics: min 4.5 bar/60 Psi
Electrical: 200~230V, 3A, single phase
Emergency Button
Dimension: W615 X D685 X H1643 mm
Weight: 210 kgs
