Width: 5.13 mm
Height: 1.04 mm
Length: 6.15 mm
Fall Time: 40 ns
Rise Time: 16 ns
Technology: Si
Unit Weight: 506.600 mg
Channel Mode: Enhancement
Configuration: Single
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 101 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 100 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 16 ns
Typical Turn-Off Delay Time: 150 ns
Id - Continuous Drain Current: 32 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 35 S
Rds On - Drain-Source Resistance: 25 mOhms
Vds - Drain-Source Breakdown Voltage: 80 V
Vgs th - Gate-Source Threshold Voltage: 1.5 V
