Fall Time: 76 ns
Rise Time: 38 ns
Technology: Si
Unit Weight: 4 g
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 48 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 32 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 21 ns
Typical Turn-Off Delay Time: 71 ns
Id - Continuous Drain Current: 17.4 A
Maximum Operating Temperature: + 155 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 4 S
Rds On - Drain-Source Resistance: 205 mOhms
Vds - Drain-Source Breakdown Voltage: 800 V
Vgs th - Gate-Source Threshold Voltage: 4 V
