Fall Time: 8 ns
Rise Time: 10 ns
Technology: Si
Unit Weight: 506.600 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 167 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 104 W
Vgs - Gate-Source Voltage: - 16 V, + 20 V
Typical Turn-On Delay Time: 19 ns
Typical Turn-Off Delay Time: 50 ns
Id - Continuous Drain Current: 208 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 120 S
Rds On - Drain-Source Resistance: 1.2 mOhms
Vds - Drain-Source Breakdown Voltage: 45 V
Vgs th - Gate-Source Threshold Voltage: 1.1 V
