Testing frequency
10Points(100,120,200,400,800,1K,2K,4K,8K,10K)
Display screen: 3.5” TFT LCD screen
Number of display digits
Principal parameter: 5 digit
Secondary parameter: 5 digit
Measured parameter:
Principal parameter: L/C/R/Z
Secondary parameter: X/D/Q/θ/ESR
Measurement range
L:0.001µH～99999H,
C:0.001pF～99.999mF,
R:0.0001Ω～99.999MΩ
Basic accuracy: 0.2%
Measuring display speed: 2 time/s (slow), 4 times/s (medium), 8 time/s (fast)
Internal bias: 0-1500mV adjustable, at a step of 1mV.
Testing level: Six fixed level(0.1V,0.3V,0.6V,1V,1.5V ,2V)
Signal source output impedance: 30Ω,100Ω
Calibration function: Open circuit calibration, short circuit calibration
Screening function: The limit range of screening can be set to -50%～＋50%, and the fixed points are 1%, 5%, 10% and 20%.
Comparator: 5 groups sorting,3 groups of qualified setting, one group of unqualified setting, one group of auxiliary setting
Interfaces: standard: RS232(or 485), USB Device, Handler ;optional :GPIB,USB Host
Others: Support dc resistance (DCR), electrolytic capacitor measurement model,Adjustment of backlight brightness, Chinese and English are optional
