Relative Humidity
Measurement range: 0 … 100 %RH
Accuracy (incl. non-linearity, hysteresis, and repeatability) over temperature
range:
0 … +40 °C
0 … 90 %RH: ±1.5 %RH
90 … 100 %RH: ±2.5 %RH
−40 … 0 °C and +40 … +80 °C
0 … 90 %RH: ±3.0 %RH
90 … 100 %RH: ±4.0 %RH
Factory calibration uncertainty at +20 °C:
0 … 90 %RH: ±1.1 %RH
90 … 100 %RH: ±1.8 %RH
Humidity sensor: HUMICAP 180R
Stability: ±2 %RH over 2 years
Temperature
Measurement range: −40 … +80 °C
Accuracy over temperature range:
0 … +40 °C: ±0.2 °C
−40 … 0 °C, +40 … +80 °C: ±0.4 °C
Temperature sensor: Pt1000 RTD Class F0.1 IEC 60751
Probe weight with standard cable: 31 g
Probe housing material: Stainless steel
Probe filter and sensor protection: Membrane filter with chrome coated ABS plastic
Cable material: Wire PVC / Jacket PU
Cable connector: TRRS male 3.5 mm
Probe housing: IP rating IP65
Borehole diameter needed: 16 mm
Measurement depth with standard accessories: Min. 30 mm, max. 90 mm
