Technical Data
IR resolution (Pixels): 120×90
Field of view(FOV): 50°×38°
Thermal sensitivity(NETD): ≤60mK @25℃
Spatial resolution(IFOV): 7.3mrad
Frame rate: ≤25Hz
Focus: Focus free
Lens focal length: 2.28mm
Temperature measurement range: -20℃ ~ 400℃
Accuracy: ±2℃ or ±2% whichever is greater
Emissivity: 0.01~1.00 adjustable (0.95 default)
Functions
Color palettes: 7 (White hot, Lava, Ironbow,Black hot, Red hot, Rainbow, Rainbow HC)
Image modes: Thermal,Fusion,PIP
On screen analyzer: 6 Points/6 Lines/6 Rectangles/6 Circles
Hi/Lo temperature alarm: √
Video recording: √
General Characteristics
USB: Lightning
Drop proof: 1m
Image/Video storage format: JPEG, MP4
Certificates: CE,UKCA,FCC,RoHS,MFi
Languages: ZH, EN
Product net weight: 25g
Product size: 53mm×18.2mm×18.5mm
Packing Details
Standard accessories: English manual, Documents download operation guide card
Standard individual packing: Gift box
Standard Qty per carton: 20pcs
Standard carton size: 290mm×265mm×325mm
Standard carton G.W.: 4.8kg
