Measurements: V,A,W,PF/HZ
Measurement method: AC DC AC+DC(T-RMS)
Voltage: Range: 3.0V-600V(75V/150V/300V/600V)
Accuracy: ± (0.4% reading + 0.1 range + 1 digit)
Resolution: 0.01V
Current: Range: 0.5mA-20.0A(500mA/2A/8A/20A)
Accuracy: ± (0.4% reading + 0.1 range + 1 digit)
Resolution: 0.0001A /0.001A/0.01A
Power: Range: 1W~12kW
Accuracy: ± (0.4% reading + 0.1 range + 1 digit)
Resolution: 0.001W/0.01W/0.1W/1W
Power factor: Range: -1.000~1.000
Accuracy:± (0.4% reading + 0.1 range + 1 digit)
Frequency: Range: Fundamental frequency: 40Hz ~ 130Hz, bandwidth: 5kHz
Accuracy:±(0.1%reading+1digit)
Harmonic analysis: Times: _
Accuracy: _
Range switching: Auto / manual
Automatic range switching: Range increase: The measured value exceeds about 110% of the rated range (CF< 3)
Range reduction: The measured value is less than about 30% of the rated range (CF< 3)
Preheating time: >30min
Peak current: Maximum display 24A
Maximum input allowed for connection: Voltage700V， Current 24A
Instantaneous allowable maximum input: 1000V,40A(1s)
Input impedance: Voltage: > 5 MΩ, current: < 0.02 Ω
Upper and lower limit function: Four settings for upper and lower limits of power and current: P Hi (Power high),P Lo(Power low),A Hi(Current high),A Lo(Current low)
Interface: RS232， RS485
9600、 19200、 38400、 115200 optional
Display hold: Yes
Loudspeaker mute: Yes
Key lock: Yes
Power: AC 100V~240V ,50/60Hz
Display: VA Broken code screen, 5 digits, four windows
Product net weight:2.7kg
Product size (W×H×D): 214mmx88mmx340mm
