Specifications:
Current(ACA): 60.0A/600.0A/6000A/10000A
Frequency response(ACA): 45~400Hz
Resolution & Accuracy: 0.01A; ±(2%+5)
Inrush current: 6000A
Voltage(ACV): 1000V
Accuracy (ACV): ±(1.2%+3)
Voltage(DCV): 1000V
Accuracy (DCV): ±(1.2%+3)
Resistance: 60.00MΩ: ±(1.0%+5)
Frequency: 10.00Hz~30.00kHz: ±(0.5%+3)
Active power: /
Apparent power: /
Reactive power: /
Power factor: /
Electric energy: /
Phase sequence: /
Features:
True RMS: √
Display count: 6000
Sampling rate: 3times/s
Data storage: /
Data hold: √
Backlight: √
Power supply: 1.5V AAA×3
Data communication: /
Meter’s Dimension: 145 x 58 x 33mm
Length flexible coil: 43.30″(1100mm)
Coil inner dia.: radius: 6.26″ (15.92cm)
Coil dia.: Φ8mm
Dimension(LCD): 35mm*32mm
Warning indication: High voltage & OL
2m drop test: /
Overvoltage rating: CAT III 1000V & CATⅣ 600V
Certificates: CE/ETL/ROHS
