DC voltage (V): 600V ±(0.5%＋3)
AC voltage (V): 600V ±(0.7%＋3)
LoZ ACV (V): 600V ±(2%＋5)
ACV LPF: 600V ±(2%＋5)
DC current (A): 20A ±(0.8%+3)
AC current (A): 20A ±(1%+3)
Resistance (Ω): 60MΩ ±(0.8%+2)
Capacitance (F): 60mF ±(3%+5)
Frequency (Hz): 10Hz~1MHz ±(0.1%+4)
Duty cycle: 0.1%~99.9% ±(2%＋5)
Temperature (°C): -40°C~400°C (0.1°C resolution) ±(1%+20)
Temperature (°F): -40°F~752°F (0.2°F resolution) ±(1%+40)
ACV peak hold: ±(2%+100)
Peak current detection: ±(3%+100)
Power: 9V battery
Display: 58mm x 42mm
Product color: Red and grey
Product net weight: 428g
Product size: 180mm x 87mm x 59mm
Standard accessories: Test lead, battery, carrying bag, point contact temperature probe
Features:
Display count: 6000
Auto range: Yes
Bandwith (Hz): 40Hz~400Hz
True RMS: Yes
Diode test: Yes
Peak hold: Yes
Continuity buzzer: Yes
NCV: No
MAX/MIN: Yes
Relative mode: Yes
VFC/LPF: Yes
Analog bar: Yes
Data hold: Yes
Auto power off: Yes
LCD backlight: Yes
Input alarm: Yes
Input impedance: ≥10MΩ
Category ratings: CAT III 600V
IP rating: IP 65
Drop test: 2m
