Rated Output:
Voltage: 0~30V
Current: 0~20A
Power: 600W
O.V.P Range: DC 1~100% of rated output
O.C.P Range: Fixed DC 105% of maximum output
Current Stability: CV ≤0.2% +2 digits; CC ≤0.5% +2 digits
Load Stability: ≤0.5% +2 digits
Ripple and Noise (5Hz~1MHz): ≤1% rms full scale
Display:
Voltmeter: 4-digit LED display
Ammeter: 4-digit LED display
Voltage Resolution: 0.000-9.999V; 00.00-99.99V; 000.0-999.9V
Current Resolution: 0.000-9.999A; 00.00-99.99A; 000.0-999.9A
Accuracy: ±(1% FS +1 digit)
Optional Functions:
Meter Display: 4 1/2 digit LED display (Maximum display 19999)
Output Terminals: On the front panel; or on the rear panel; or on both front and rear panels
Output On/Off: Front panel switch; Terminal block or rear panel wires for remote control
General Specifications:
Protection: Over-voltage, over-current, over-temperature, and overload protection
Operating Environment: 0℃~40℃, ≤80% RH
Storage Environment: -10℃~70℃, ≤80% RH
Input Module: Power socket or terminal block
