Constant voltage operation
Line regulation: ≤0.05%+1mV
Load regulation: ≤0.1%+5mV
Ripple & Noise: ≤10mVrms
Constant current operation
Line regulation: ≤0.05%+10mA
Load regulation: ≤0.1%+10mA
Ripple & Noise: ≤20mArms
Display
Voltmeter: 3 digits LED display
Ammeter: 3 digits LED display
Resolution: 100mV/10mA
Accuracy: ±(1% reading+1 digit)
General
Protection
Over current protection, fixed 105% of rated current.
Over voltage protection, fixed 105% of rated voltage.
Over temperature protection: when internal temperature reaches 65℃±5℃, OTP is activated and the output will be shut down.
Operating environment: 0℃~40℃, ≤80%RH
Storage environment: -10℃~70℃, ≤70%RH
Power source: AC115V/230V±10% selectable, 50/60Hz
Accessories: Power cord x1, Operation manual x1
Dimension
S2 chassis: 125Wx160Hx260D mm
S3 chassis: 150Wx140Hx280D mm
Weight: Approx.2kg
