Life: 100000 Cycle
Taper: Reverse Audio
Width: 9.5 mm
Height: 11.35 mm
Length: 13.3 mm
Features: Side Adjust
IP Rating: IP50
Tolerance: 20 %
Resistance: 1 kOhms
Shaft Type: Flatted / D
Orientation: Horizontal
Switch Type: Rotary Switch
Thread Size: M7 x 0.75
With Switch: With Switch
Bushing Size: 5 mm
Element Type: Conductive Plastic
Power Rating: 25 mW (1/40 W)
Shaft Length: 10 mm
Bushing Thread: M7 x 0.75
Mounting Style: Panel Mount
Shaft Diameter: 6 mm
Voltage Rating: 50 VAC
Number of Gangs: 1 Gang
Number of Turns: 1 Turn
Bushing Material: Metal
Number of Detents: Without Detent
Termination Style: PC Pin
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 10 C
