Technical data:
Idle speed 1. Speed level: 0 - 1.250
Impact frequency combined 1. Speed level: 0 - 6.400 min-1
Impact energy [Joule]: 2.1
Maximum drilling diameter:
Wood [mm]: 30
Metal [mm]: 13
Masonry / bricks [mm]: 24
Electrical values:
Mains connection: 230 V, 50 Hz
Power input [W]: 620
Connection plug: CEE 7/17
Cable length [m]: 3
Protection class: II
Sound values according to EN 60745:
Sound pressure level hammer drilling [[dB(A)]]: 84.94
Sound power level hammer drilling [[dB(A)]]: 95.94
Uncertainty (K) [dB]: 3
Sound pressure level chiselling [[dB(A)]]: 91.26
Sound power level chiselling [[dB(A)]]: 102.26
Uncertainty (K) [dB]: 3
Vibration information according to EN 60745:
Vibration emission value (ah) Impact drilling in brickwork with main handle [m/s²]: 12.875
Uncertainty (K) Impact drilling in brickwork with main handle [m/s²]: 1.5
Vibration emission value (ah) Impact drilling in brickwork with additional handle [m/s²]: 11.953
Uncertainty (K) Impact drilling in brickwork with additional handle [m/s²]: 1.5
Dimensions:
Length (packaging excluded) [mm]: 355
Width (packaging excluded) [mm]: 85
Height (packaging excluded) [mm]: 210
Weight:
(packaging excluded) [kg]: 3
