Layer thickness measurement:
Functional principle | Layer thickness: Magnetic induction, Turbulent flow
Material | Layer thickness: Ferromagnetic ground, Non-ferrous metal ground
Min. measuring range [µm]: 0
Max. measuring range [µm]: 2000
Accuracy: ±0.1 µm (at 0 µm up to 100 µm)
: ±1 µm (at 100 µm up to 1,000 µm)
: ±0.01 mm (at 1,000 µm up to 2,000 µm)
Tolerance | Non-ferrous metal ground Guaranteed tolerance with non-ferrous metal ground in the measuring range from 0 to 1,000 µm: (±2 % + 2) µm of measured value
Tolerance | Non-ferrous metal ground Guaranteed tolerance with non-ferrous metal ground in the measuring range from 1,000 to 2,000 µm: ±3.5 % µm of measured value
Tolerance | Ferromagnetic ground Guaranteed tolerance with ferromagnetic ground in the measuring range from 0 to 1,000 µm: (±2 % + 2) µm of measured value
Tolerance | Ferromagnetic ground Guaranteed tolerance with ferromagnetic ground in the measuring range from 1,000 to 2,000 µm: ±3.5 % µm of measured value
Minimum measuring surface with non-ferrous metal ground: Ø 5 mm
Minimum bending radius with non-ferrous metal ground: 3 mm
Critical primary layer thickness of non-ferrous metal ground: 0.3 µm
Minimum measuring surface with ferromagnetic ground: Ø 7 mm
Minimum bending radius of the measuring surface with ferromagnetic ground: 1.5 mm
Critical primary layer thickness of ferromagnetic ground: 0.5 µm
Memory organisation:
Internal flash memory: Up to 2,500 measured values
Recall of previous measurements: ✓
Display:
LCD: ✓
Monochrome: ✓
Device control:
Push buttons: ✓
Ambient conditions:
Operation - min. temperature [°C]: 0
Operation - max. temperature [°C]: 40
Operation – min. relative humidity [% r.F.]: 20
Operation - max. relative humidity [% r.F.]: 90
Dimensions:
Length (packaging excluded) [mm]: 114
Width (packaging excluded) [mm]: 27
Height (packaging excluded) [mm]: 54
Weight:
(packaging excluded) [kg]: 0.152
