- Performance:
Measurement Range : 0 to ±40 V DC or peak AC.
Sensitivity: 1 mV
Accuracy: Voltage Monitor Output : Better than ±0.05% of full scale; Voltage Display: Better than or equal to ±2 counts, referred to the voltage monitor.
Speed of Response (10% to 90%): At Fastest Speed Setting: Less than 3 ms for a 10 V step; At Slowest Speed Setting: Less than 5 ms for a 10 V step.
Noise (typical): Less than 1 mV rms, referenced to measured voltage.
Stability: Drift with Time: Less than 50 ppm/hour, noncumulative.
Drift with Temperature: Less than 50 ppm/°C (1:1 monitor output); Less than 100 ppm/°C (10:1 monitor output).
- General:
Dimension: 108 mm H x 223 mm W x 370 mm D (4.25" H x 8.75" W x 14.5" D).
Weight: 3.6 kg (8 lb).
Voltage Monitor Connector: BNC connector.
Ground Receptacle: Banana jack.
AC Line Cord Receptacle: Standard three-prong line cord with integral fuse holder
Line Supply: 180 to 250 V AC at 48 to 63 Hz
