Width: 13.7 mm (0.539 in)
Height: 10.2 mm (0.402 in)
Length: 23.8 mm (0.937 in)
Industry: Industrial
Unit Weight: 8.800 g
Output Power: 15 W
Input Voltage: 9 V to 36 V
Mounting Style: Through Hole
Isolation Voltage: 1.5 kV
Number of Outputs: 2 Output
Input Voltage - Max: 36 V
Input Voltage - Min: 9 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 500 mA
Output Current-Channel 2: 500 mA
Output Voltage-Channel 1: 15 V
Output Voltage-Channel 2: - 15 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
