Technical Data
Traverse speed: 1 - 60 cycles per minute
Traverse speed accuracy: + / - 1% of set speed
Stroke length: 20 - 300 mm / 0.39 - 11.81 in
Stroke length accuracy: + / - 0.01 mm
Pump flow rate: 0.0 - 3.0 ml per minute / 0.0 - 0.79 GPH
Max. panel width: 70 mm / 2.76 in
Max. panel length: 350 mm / 13.78 in
Max. panel height: 35 mm / 1.38 in
Dimensions and Weight
Depth: 490 mm / 19.3 in
Depth with pumps: 530 mm / 20.87 in
Width: 640 mm / 25.2 in
Height: 235 mm / 9.24 in
Mass: 30 - 35 kg / 66.14 - 77.16 lbs (depending on model)
Basic Unit
Power Supply: 24 VDC / 100 - 240 V / 50 - 60 Hz
Power consumption: max. 90 Watt
Display: 480 x 272 pixel TFT display
Control: 5-key navigation switch (Mouse Keyboard optional)
Menu languages: English, Spanish, Chinese, Polish, German, French, Italian, Japanese, Russian, Turkish
Scope of Supply
>> Standard supplied:
• 24V adapter + Power Cable
• Manual
>> Only supplied with AB6000:
• Scrub Abrasion and Washability Tester
• Tubing
• Fluid containers
