Continuity Resistance Ranges
Measuring Ranges: 20.00Ω / 200.0Ω
Accuracy: ±3% rdg. ±3dgt. ±0.1Ω
Insulation Resistance Range
Test Voltage: 250V/500V/1000V
Measuring Ranges: 20.00MΩ/200.0MΩ/2000MΩ
Loop Impedence Range
Rated Voltage: 230V AC ±10%
AC Voltage Measuring Range: MAX 253V AC
PSC
Rated Voltage: 230V AC ±10%
AC Voltage Measuring Range: MAX 253V AC
RCD Ranges
Rated Voltage: 230V AC ±10%
AC Voltage Measuring Range: MAX 253V AC
AC Voltage Ranges
Measuring Ranges: 200V/600V
Input Impedance: Approx. 10MΩ
Input Frequency: 45Hz - 450Hz
Accuracy: ±3% rdg. ±5dgt.
DC Voltage Ranges
Measuring Ranges: 200V/1000V
Input Impedance: Approx. 10MΩ
Accuracy: ±3% rdg. ±3dgt.
Earth Resistance Ranges
Measuring Ranges: 20Ω/200Ω/2000Ω
Operating Temperature: 0°C - 40°C
Storage Temperature; -10° - 50°C
Operating Humidity: 70% max.
Storage Humidity: 80% max.
Dimensions: 170 x 210 x 90mm
Power Supply: 8 x 1.5V Battery (AA or R-6)
Battery Life: 100 Hours
