Width: 5 mm
Height: 0.73 mm
Length: 5 mm
Fall Time: 15 ns
Rise Time: 9.6 ns
Technology: Si
Unit Weight: 104 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 74 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 142 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 23 ns
Typical Turn-Off Delay Time: 89 ns
Id - Continuous Drain Current: 150 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 1 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 1.3 V
