Fall Time: 22 ns
Rise Time: 25 ns
Technology: Si
Unit Weight: 360 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 12 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 80 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 50 ns
Typical Turn-Off Delay Time: 70 ns
Id - Continuous Drain Current: 3 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 4.9 Ohms
Vds - Drain-Source Breakdown Voltage: 800 V
Vgs th - Gate-Source Threshold Voltage: 2.5 V
