Width: 4.5 mm
Height: 20 mm
Length: 15.5 mm
Fall Time: 35 ns
Rise Time: 40 ns
Technology: Si
Unit Weight: 4.600 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 46 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 250 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 80 ns
Typical Turn-Off Delay Time: 140 ns
Id - Continuous Drain Current: 10 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 700 mOhms
Vds - Drain-Source Breakdown Voltage: 800 V
Vgs th - Gate-Source Threshold Voltage: 4 V
