Unit Weight: 16 mg
Logic Family: SH
Logic Function: XOR
Mounting Style: SMD/SMT
Output Voltage: 0 V to 5.5 V
Number of Gates: 1 Gate
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2 V
Number of Input Lines: 2 Input
Number of Output Lines: 1 Output
Pd - Power Dissipation: 200 mW
Propagation Delay Time: 4.8 ns
Low Level Output Current: 8 mA
High Level Output Current: - 8 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
