Logic Type: CMOS
Unit Weight: 6.200 mg
Logic Family: LVP
Logic Function: OR
Mounting Style: SMD/SMT
Output Current: 8 mA
Output Voltage: 0 V to 3.6 V
Number of Gates: 1 Gate
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 2.3 V
Number of Input Lines: 2 Input
Number of Output Lines: 1 Output
Pd - Power Dissipation: 200 mW
Propagation Delay Time: 3.2 ns
Low Level Output Current: 8 mA
High Level Output Current: - 8 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
