Number of units: 8 separate channel
Withstanding voltage test
- Output voltage:
AC 0.10kV — 5.00kV ±2%
DC 0.10kV — 6.00kV ±2%
- Current test Range:
AC: 0mA — 10.00mA ±(2% readings + 5 digits)
DC: 0uA — 5.00mA ±(2% readings + 5 digits)
Rapid discharge function: Discharge after test ends (DCW)
Insulation resistance test:
Output voltage: 0.10kV — 1.00kV ±2%
Resistance test range: 0.1MΩ — 10.0GΩ
Resistance test accuracy:
0.10MΩ — 999MΩ ±10%
1.00GΩ — 10.0GΩ ±20%
Discharge function: Discharge after test ends
Arc detection
Test range: Corresponding current 1mA — 20mA
General specification:
Voltage rising time: 0.1s — 999.9s
Test time setting (AC/DC): 0.2s — 999.9s
Voltage fall time: 0.1s — 999.9s
Waiting time (IR): 0.2s — 999.9s
Time accuracy: ±(1%+0.1s)
Memory: Store 100 test files and each file can hold at most 20 testing steps
Interface:
Standard HANDLER, RS232, USB DRV, USB HOST
