Test parameter: |Z|, C, L, X, B, R, G, D, Q, θ
Basic accuracy: 0.05%
Measuring speed:
- Slow: 1.5meas/sec
- Med: 10meas/sec
- Fast: 30meas/sec
Signal frequency: 50Hz to 200kHz , over 12,000 points
Output impedance; 30Ω , 100Ω
Test Level: 10mVrms~2.0Vrms, 10mV steps
Dải hiển thị:
- |Z|, R, X: 0.00001Ω — 99.9999MΩ
- C: 0.00001pF — 9.99999F
- L: 0.00001μH — 99.9999kH
- G,B: 0.00001μS — 999.999S
- D: 0.00001 — 9.99999
- Q: 0.00001 — 99999.9
- θ(DEG): -179.999º — 179.999º
- θ(RAD): -3.14159 — 3.14159
- Δ%: -999.999% — 999.999%
Instrument Accessories
TH26005A 4 terminal test fixture
TH26011A 4 terminal Kelvin test clip leads
TH26010 Gilded shorting plate
Options
TH26047 4 terminal test fixture
TH26048 4 terminal test fixture
TH26006 Axial component test fixture
TH26007A Core inductor test fixture
TH26008A SMD component test fixture
TH26009B SMD Kelvin test tweezers
TH26033 GPIB interface cable
TH26034 RS232C interface cable
TH10001 GPIB interface board
TH12003 RS232C control software(TH2816A)
TH12004 RS232C control software(TH2817A)
