Inner Size（W*D*H mm）: 390L（1000*600*650）
Outer Size(Excluding rotrusions)W*D*Hmm: 1200*2273*2000
Outer Size(Including protrusions) *D*Hmm: 1296*2476*2210
Temperature Range: -40~150℃
Humidity Range: 10~98%RH
Heating Rate: 2℃/min
Cooling Rate: 1℃/min
Temperature Uniformity: ≤2℃（-40℃~100℃）others≤3℃
Humidity Deviation: ±3.0%RH(＞75%RH);±5.0%RH(≤75%RH)
Temperature Deviation: ≤±2℃
Temperature Fluctuation: ≤1℃
Humidity Fluctuation: ≤±2.0%RH
Temperature Accuracy: 0.1℃
Humidity Accuracy: 0.1%RH
Maximum Heat Dissipation: 13200
Humidification Water Inlet Way: AUTO
Refrigerant: R404A
Humidification pipe specifications: 6mm
Drainage pipe specifications: 10mm
Weight: 1200
Inner Chamber material: SUS304δ0.8mm
Outer Chamber material: SPCC+Coatingδ1.5mm
Appearance: RAL9006
Insulation materials: Glass wool+phenolic foam board
Noise: ≤70d(B) Test at a height of 1.2m and 1m directly ahead
Window Size: 245*250mm
Cooling Type: Air cooling (forward air, rear air outlet)
Test Hole: 100mm*1（LEFT centre）
Sample holder specifications: 20kg/PCS,Two layer （total 4 PCS）
Voltage: AC380V±10% 50Hz±10%
Max Power(KW): 22KW
Maximum Current（A）: 40A
Leakage Switch（A）: 50A
