Voltage AC: AC220V, 50HZ
Heating Power: 6KW
Furnace tube size: 100x1000mm(out diameter*length)
Furnace tube material: Corundum tube
Heating Zone: 300mm
Constant Temperature Zone: 150mm
Max working Temperature: 1400℃
Long-term working temperature: 1300℃
Heating unit: Silicon carbon rod
Heating Rate: 1-20 ℃ / min adjustable
Suggested heating rate: 3 ℃ / min temperature rise rate
Temperature control precision: ±1℃
Passable atmosphere: Co2,Nitrogen, argon, etc.
Temperature measuring elements and temperature measuring range: S thermocouple, temperature range 0-1400 ℃
Original electric appliance: Partial selection of Schneider imported brands
Instrument control: Yudian GP518P
Sealing Component: Custom seal flange
Vacuum: 200pa Digital vacuum gauge
Flowmeter(optional): 50-500ml/min
Control Method: Control mode: Adopt automatic control system
Programming curve segment number: The 31 paragraph can be adjusted to reduce the unnecessary trouble caused by artificial timing.
Display accuracy: ±1℃
Digital display: Measuring temperature and setting temperature double display
Control characteristics: Control system modular structure
Air cooling system: The fan impeller is mounted directly on the bottom of the double furnace shell and assembled with the control system.
