Test Currents: 1 Ma - 10 Ma - 100 Ma - 1 A - 5 A - 10 A. Each Current May Be Continuously Adjustable From 0 To 100%.
Resistance Ranges
0-200 Mω @ 10 A.
0-1,000 Mω @ 5 A.
0-200 Mω @ 1 A.
0-2,000 Mω @ 100 Ma.
0-20 Ω @ 10 Ma.
0-2,000 Ω @ 1 Ma.
Accuracy Of Test Current: ± 3%.
Resolution: 0.1 µω @ 10 A.
Output Voltage: Up To 10 Vdc (Open Circuit) @ 1 A.
Measurement Principle: Four-Terminal, Kelvin-Type.
Basic Accuracy Of Resistance Measurement: ±(0.10% Of Reading + 3 Ulsd*).
*Units Of The Least Significant Digit.
Voltage Measurement: 0 V - 5 V.
Accuracy Of Voltage Measurement: ± 5%.
Advanced Features: Digital Direct Reading Of Very Low Resistances In The Alphanumerical Display, With Up To 4½ Digits. Very Fast And Accurate Measurements. Built-In Printer.
Built-In Memory: For Up To 30,000 Measured Values.
Serial Data Output: Usb.
Environmental: Ip54 With Closed Lid.
Safety Class: Meets The Requirements Of Iec 61010-1.
Power Supply: Rechargeable Lfp Battery 12 V, 6000 Mah Or 100 - 240 V~ Mains Supply.
Battery Charger: For 100 - 240 V~ Mains Supply Or Auxiliary 12 V Supply Input.
Operating Temperature Range: -5 °C To +50 °C.
Storage Temperature Range: -25 °C To +70 °C.
Humidity Range: 95% Ur (Non Condensing).
Equipment Weight: Approx. 6.5 Kg.
Dimension: 378 X 308 X 175 Mm.
Available Accessories
2 Combined Current And Potential Leads.
1 Ground Cable.
1 Power Cord.
1 Usb Cable.
1 Auxiliary External Power Cord (12 V – Charge).
1 Auxiliary External Power Cord (12 V – Charge Or Measure).
1 Temperature Sensor.
1 User Guide.
1 License To Use The Software.
1 Case For The Accessories.
