Test voltages: 500, 1000, 2500, 5000 V directly, one button selectable. 500 V to 5 kV in 100 V increments. DC, negative.
Maximum resistance reading: 5 TΩ @ 5 kV.
Short circuit current: 1.5 ± 0.5 mA.
Test voltages accuracy: ± 3 % of nominal test voltages on R ≥ 10 GΩ.
Insulation tester basic accuracy:
± 5 % of reading from 1 MΩ up to 1 TΩ.
± 20 % of reading from 1 TΩ up to 5 TΩ.
Advanced features:
Automated polarization index calculation.
Automated dielectric absorption ratio calculation.
Step voltage test.
Programmable pass / fail test.
Built-in printer: Prints elapsed time, actual voltage and resistance measured each 15 seconds.
Built-in memory: Stores up to 4000 measured values.
Interface: USB.
Built-in chronometer: Shows elapsed time in mm:ss format. Count starts automatically for each measurement.
Real time clock and calendar: Allows a reliable identification for each test.
T-Logger software: Friendly, easy to use software. Tests are represented in graphical and tabular views. With automatic report generator, including the operator's commentaries.
Environmental protection: IP54 (with closed lid).
Safety class : In accordance with IEC 61010-1.
E.M.C.: In accordance with IEC 61326-1.
Electrostatic immunity: In accordance with IEC 61000-4-2.
Electromagnetic irradiation immunity: In accordance with IEC 61000-4-3.
Power supply: Internal rechargeable LFP 12 V - 3000 mAh battery.
Battery charger: 12 V - 2 A.
Operating temperature range: 23 °F to 122 °F (-5 °C to 50 °C).
Storage temperature range: -13 °F to 158 °F (-25 °C to 70 °C).
Humidity range: 95 % RH (non condensing).
Equipment weight: Approx. 7.94 lb (3.6 kg).
Dimensions: 10.78" x 9.84" x 4.88" (274 x 250 x 124 mm).
Included accessories:
2 Measuring test leads.
1 GUARD test lead.
1 AC Adapter.
1 T-Logger software (CD-ROM).
1 User guide.
1 Protective bag.
1 USB cable.
