Resistance Range: 20mΩ (10–60A) to 6kΩ (10mA)
Resolution: 0.01mΩ e.g. 150.01mΩ (4-1/2 digit)
Accuracy: ±0.1% of reading
Max. Voltage: 60V pure DC (Noise < 10mVpp)
Max. Current: 60A pure DC
Selectable max. current: 10mA to 60A, limited by total resistance (cable + object)
Measuring time: Short due to very fast charge with 60V available
Discharge time: Typically 1/10 of charging time
Measuring inputs: Measuring inputs 2 Current, 4 Potential (2 channels)
Temperature input: Connector for PT100 (correction for 20/23°C for Cu or Al)
Tap changer: Connector for automatic up/down control
Warning system: Connector for red/green warning lamps
External start: Connector for measurement start via external contact
External current supply: Connector for controlling currents up to 600 A, automatically extends range down to 2mW (resolution 0.001mW = 1nW)
Mains: 85 to 260 VAC, 6.5A, Auto ranging
Display: LCD 240 × 128 with back light
Interface: RS232C
Printer: Built-in thermal printer
Test storage: Up to 1000 results
Environment (operating): −10°C to 50°C
Environment (storage): −30°C to 60°C
Environment (humidity): 0 – 90% R/H max., non condensing
Size (without cables): 490 × 400 × 190 mm (WxDxH, mobile ABS rugged case)
Weight (without cables): Approx. 15kg
Cables: Various options available
Safety and EMC: CE, IEC-1010-1, EN55022 B, EN61000-3-2, ENV50204
